Materials

ALL MATERIALS

Onyx

MARKFORGED

Strong, tough, and flexible

Carbon fiber filled nylon 6

Technical Datasheet
Process: FDM/CFR 3D Printing
Tensile Strength at Yield

40 MPa | 5.8 ksi

Tensile Modulus

2.4 GPa | 348 ksi

Elongation at Break

25%

Impact Strength (Notched)

330 J/m | 6.18 ft-lb/in

Heat Deflection Temperature

145 °C | 293 °F

Onyx FR

MARKFORGED

Flame resistant, strong, tough, and flexible

V-02 FR carbon fiber filled nylon 6

Technical Datasheet
Process: FDM/CFR 3D Printing
Flame Resistance

V-02

Tensile Strength at Yield

41 MPa | 6 ksi

Tensile Modulus

3.0 GPa | 435 ksi

Elongation at Break

18%

Heat Deflection Temperature

145 °C | 293 °F

Onyx ESD

MARKFORGED

Electrostatic dissipating, strong, tough, and flexible

ESD carbon fiber filled nylon 6

Technical Datasheet
Process: FDM/CFR 3D Printing
Surface Resistance

105 - 107

Tensile Strength at Yield

52 MPa | 7.5 ksi

Tensile Modulus

4.2 GPa | 609 ksi

Elongation at Break

25%

Impact Strength (Notched)

44 J/m | 0.82 ft-lb/in

White Nylon

MARKFORGED

Non-abrasive, dyeable, and paintable

White nylon 6

Technical Datasheet
Process: FDM/CFR 3D Printing
Tensile Strength at Yield

51 MPa | 7.4 ksi

Tensile Modulus

1.7 GPa | 247 ksi

Elongation at Break

150%

Impact Strength (Notched)

110 J/m | 2.06 ft-lb/in

Flextural Strength

50 MPa | 7.3 ksi

Carbon Fiber

MARKFORGED

High stiffness, high tensile strength, and low weight

Carbon Fiber

Technical Datasheet
Process: CFR 3D Printing
Tensile Strength at Yield

800 MPa | 116 ksi

Tensile Modulus

60 GPa | 8702 ksi

Elongation at Break

1.5%

Impact Strength (Notched)

960 J/m | 18 ft-lb/in

Heat Deflection Temperature

105 °C | 221 °F

Kevlar

MARKFORGED

High strength, resistant to fatigue, and low weight

Kevlar

Technical Datasheet
Process: CFR 3D Printing
Tensile Strength at Yield

610 MPa | 88 ksi

Tensile Modulus

27 GPa | 3916 ksi

Elongation at Break

2.7%

Impact Strength (Notched)

2000 J/m | 37.5 ft-lb/in

Heat Deflection Temperature

105 °C | 221 °F

Fiberglass

MARKFORGED

High strength, high impact strength, and low weight

Fiberglass

Technical Datasheet
Process: CFR 3D Printing
Tensile Strength at Yield

590 MPa | 86 ksi

Tensile Modulus

21 GPa | 3046 ksi

Elongation at Break

3.8%

Impact Strength (Notched)

2600 J/m | 48.7 ft-lb/in

Heat Deflection Temperature

105 °C | 221 °F

HSHT Fiberglass

MARKFORGED

High impact strength, high HDT, and low weight

High strength high temperature fiberglass

Technical Datasheet
Process: CFR 3D Printing
Tensile Strength at Yield

600 MPa | 87 ksi

Tensile Modulus

21 GPa | 3046 ksi

Elongation at Break

3.9%

Impact Strength (Notched)

3100 J/m | 58.1 ft-lb/in

Heat Deflection Temperature

150 °C | 302 °F

3172 High Impact

HENKEL

Non-brittle, excellent for parts requiring plastic like strength

Similar to: Polypropylene

Technical Datasheet
Process: SLA 3D Printing
Tensile Modulus

1.5 GPa | 217 ksi

Tensile Strength at Yield

39 MPa | 5.7 ksi

Elongation at Break

100%

Impact Strength (Notched)

73 J/m | 1.37 ft-lb/in

Heat Deflection Temperature

52 °C | 126 °F

8195 High Rebound

HENKEL

Firm compression, extremely quick rebound, and emulates soft rubber materials

Similar to: Rubber

Technical Datasheet
Process: SLA 3D Printing
Tensile Modulus

3.6 MPa | 0.52 ksi

Tensile Strength at Break

3.3 MPa | 0.48 ksi

Elongation at Break

81%

Hardness

Shore 60A

Tear Strength

14.5 kN/m | 993 lb/ft

IND147 High Heat

HENKEL

High heat deflection temperature, tough, dimensionally stable

Similar to: Ceramic

Technical Datasheet
Process: SLA 3D Printing
Tensile Modulus

3.2 GPa | 464 ksi

Tensile Strength at Yield

67 MPa | 9.7 ksi

Impact Strength (Notched)

14.6 J/m | 0.27 ft-lb/in

Heat Deflection Temperature @ 0.46 MPa

291 °C | 556 °F

Heat Deflection Temperature @ 1.82 MPa

163 °C | 325 °F

3820 Ultra Clear

HENKEL

Optically clear, high dimensional accuracy, and heat resistant

Acrylic

Technical Datasheet
Process: SLA 3D Printing
Tensile Modulus

1.0 GPa | 145 ksi

Tensile Strength at Yield

30 MPa | 4.4 ksi

Elongation at Break

15%

Impact Strength (Notched)

35 J/m | 0.66 ft-lb/in

PlasGRAY

ASIGA

High dimensional accuracy, heat resistant, and semi-rigid

Similar to: ABS/PP

Technical Datasheet
Process: SLA 3D Printing
Flextural Strength

87 MPa | 12.6 ksi

Tensile Strength at Yield

51 MPa | 7.4 ksi

Elongation at Break

7%

Hardness

Shore 82D

Heat Deflection Temperature

84 °C | 183 °F

PlasWHITE

ASIGA

High dimensional accuracy, heat resistant, and semi-rigid

Similar to: ABS/PP

Technical Datasheet
Process: SLA 3D Printing
Flextural Strength

87 MPa | 12.6 ksi

Tensile Strength at Yield

51 MPa | 7.4 ksi

Elongation at Break

7%

Hardness

Shore 82D

Heat Deflection Temperature

84 °C | 183 °F
